Key Features
- Isolated HPF Flicker Free Drivers
- Overvoltage protection, Undervoltage protection
- Operating: 30°C – 105°C, Overtemperature protection
- Suitable for Indoor applications
- 2.5 – 4 KV Surge Protection
- 2 Years warranty
Technical Specifications
| Power | Vac | Vdc | Iout | Surge | PF |
|---|---|---|---|---|---|
| 1-3W | 100-265V | 3-10V | 300mA | 2.5KV | >0.9 |
| 4-7W | 100-265V | 12-24V | 300mA | 2.5KV | >0.9 |
| 8-12W | 100-265V | 27-40V | 300mA | 4KV | >0.9 |
| 12-18W | 100-265V | 30-42V | 300mA | 4KV | >0.9 |
| 18-24W | 100-265V | 60-80V | 300mA | 4KV | >0.9 |
| 24-36W | 100-265V | 80-120V | 300mA | 4KV | >0.9 |
